High Performance Liquid Cooling
The Mikros Ascutney Series is our base-level liquid cooling option with exceptional thermal performance. Utilizing our MikroMatrix™ cooling technology, this cold plate employs 160-micron microchannels to cool most processors and thermally active surfaces up to 300 W/cm2 with less than a 20°C rise over coolant inlet temperature. These cold plates are available for integration into an existing system or evaluation for a custom Mikros cooling solution.
Ascutney Series Technology
- High Cooling Capacity 15 W/C-cm2 (high flow), 6 W/C-cm2 (low flow)
- Low Pressure Drop Less than 5psi
- High Cooling Value Avg $0.10-$0.20 per Watt dissipated*
- High Reliability Helium Leak and Thermal Tested for over 18 years
- Tailored Cooling available with 0 deg temp gradients
- Custom Mounts available upon request
*assumes 20C temp rise
Ascutney Series Standard Offerings
Product Description
The Mikros AX-10 is an advanced 10x10 mm microchannel cold plate with lower core thermal resistance and smaller active area than our AX-25. It can be used effectively to cool high heat flux components including LEDs, Lasers, and other critical components.
Product Description
The Mikros AX-25 cold plate is a microchannel cold plate optimized for high heat flux semiconductors. With high cooling capacity and low pressure drop, it can improve performance on existing systems or evaluate Mikros’ cooling technology for custom development.
Product Description
The Mikros AX-50 is a high performance cold plate in Mikros’ first-level Ascutney series. The AX-50 combines high cooling capacity and low pressure drop for efficient thermal management of high heat flux applications or to evaluate Mikros’ cooling technology for custom development.
Product Description
The Mikros AX-NV1 is a high performance cold plate designed specifically for the Nvidia H100 GPU. Utilizing our patented MikroMatrix cooling technology, the AX-NV1 combines high cooling capacity with low pressure drop for efficient thermal management of the Nvidia H100 die as well as its peripheral components.
Product Description
Mikros Technologies’ AX-NV2 is a high performance cold plate designed specifically for the Nvidia Blackwell series of GPU’s. Utilizing our patented MikroMatrix cooling technology, the AX-NV2 combines high cooling capacity with low pressure drop for efficient thermal management of the Blackwell Core die as well as its
peripheral components.
Need Higher Performance
Check out our advanced performance series and our elite performance series to find a cooling solution that fits your application. Need a custom size or have a special request? Inquire here to work with us on a custom project.
Levels of Thermal Performance
The Mikros Peaks series is divided into three levels of cooling performance, based on more efficient levels of our proprietary MikroMatrix cooling technology. Named for beloved New England mountains, the base-level “Ascutney” series provides high performance cooling sufficient for most semiconductors up to 1kW and above. The Monadnock series employs finer microchannels for higher performance cooling with tighter thermal budgets, cooling most processors from 1kW-2kW. Our Katahdin series utilizes our most complex designs for the highest cooling power for small areas dissipating over 1kW.
